3" White 750 Lumen LED Fire-Rated Square Gimbal Recessed Kit

3" White 750 Lumen LED Fire-Rated Square Gimbal Recessed Kit delivers powerful illumination in a compact, code-compliant package. This sleek square trim integrates a high-output 750 lumen LED module, offering bright, energy-efficient light for kitchens, hallways, and living areas. The adjustable gimbal design allows you to direct light exactly where needed, highlighting artwork or task areas with precision. Its fire-rated construction meets safety standards for ceiling penetrations, providing peace of mind without sacrificing style. The clean white finish blends seamlessly with modern interiors, making it a versatile choice for new builds or retrofits.

Built for durability and performance, this recessed kit features a robust housing that withstands high temperatures while maintaining a low-profile appearance. The 3000K warm white light creates an inviting atmosphere, ideal for residential and commercial spaces. Easy to install in standard ceiling cutouts, it pairs well with dimmer switches for adjustable ambiance. Whether accenting a feature wall or providing general lighting, this fire-rated gimbal unit combines functionality with contemporary design, ensuring long-lasting, reliable brightness.

Housing is 12 1/2" wide x 9" deep x 7 3/4" high overall. Maximum hole cutout is 3 1/2".
Trim is 4 1/2" wide x 1 1/2" high. 3" aperture. For use with Koto LED module. Compatible with 3" recessed housings.
LED module is 2 1/4" wide at the top x 2" wide at the bottom x 3" high. For use with 3" or 4" Elco recessed housings and Koto twist-lock trims.
Elco complete 3" recessed lighting kit.
Includes one dimmable 10 watt LED module. 750 lumen light output, comparable to a 60 watt incandescent. 3000K color temperature. 95+ CRI.
LED averages 50,000 hours at 3 hours per day.
Powder-coated white finish over die-cast aluminum trim. Steel housing. Die-cast aluminum LED module with frosted polycarbonate lens. Line voltage - 120V.
IC-rated for use in direct contact with ceiling insulation.
Trim has 35-degree adjustability with 358-degree rotation. LED module has 38-degree beam angle.
Convenient twist-lock design for easy installation.
Housing adjusts in frame to accommodate up to 1 1/2" ceiling thickness.
ENERGY STARÂ® rated.

3" White 750 Lumen LED Fire-Rated Square Gimbal Recessed Kit
