Recessed Lighting | 3" White 950lm LED Fire-Rated Square Reflector Recessed Kit

This three-inch white 950lm LED fire-rated square reflector recessed kit from Elco Lighting features standard IC airtight new construction housing with a Pex square deep reflector trim and Koto LED module. Steel housing and a die-cast aluminum LED module with frosted polycarbonate lens deliver a sleek appearance, as a 950 lumen output comparable to a 60 watt incandescent offers energy-saving illumination. Enjoy smooth and continuous dimming with a Triac or ELV dimmer, purchased separately. This complete kit is Title 24 and JA8-2016 compliant, and is UL listed for damp and wet locations.

Specification

• Housing is 12 1/2" wide x 9" deep x 7 3/4" high overall. Maximum hole cutout is 3 1/2".
• Trim is 4 1/2" wide x 2" high. 3" aperture. For use with Koto LED module. Compatible with 3" recessed housings.
• LED module is 2 1/4" wide at the top x 2" wide at the bottom x 3" high. For use with 3" or 4" Elco recessed housings and Koto twist-lock trims.
• Elco complete 3" recessed lighting kit.
• Includes one dimmable 10 watt LED module. 950 lumen light output, comparable to a 60 watt incandescent. 3000K color temperature. 95+ CRI.
• LED averages 50,000 hours at 3 hours per day.
• Powder-coated white finish over die-cast aluminum trim. Steel housing. Die-cast aluminum LED module with frosted polycarbonate lens. Line voltage - 120V.
• IC-rated for use in direct contact with ceiling insulation.
• LED module has 38-degree beam angle.
• Convenient twist-lock design for easy installation.
• Housing adjusts in frame to accommodate up to 1 1/2" ceiling thickness.
• ENERGY STAR® rated.
